Seamless line pipes are cylindrical, hollow tubes made from alloy or carbon steel, manufactured without any welding seams. They are produced through processes like hot extrusion or rotary piercing, ensuring a uniform structure and high strength.
These pipes are specifically designed for the transportation of fluids, such as oil, gas, and water, over long distances. They are manufactured to meet stringent standards, such as API 5L (American Petroleum Institute) and ASTM A106 (American Society for Testing and Materials), to ensure reliability and performance in demanding environments.
| Standard | Grade | Chemical Components (%) | Mechanical Properties | |||||
| C | Si | Mn | P | S | Tensile STrength(Mpa) | Yield STrength(Mpa) | ||
| API 5L PSL1 | A | 0.22 | - | 0.9 | 0.03 | 0.03 | ≥331 | ≥207 |
| B | 0.28 | - | 1.2 | 0.03 | 0.03 | ≥414 | ≥241 | |
| X42 | 0.28 | - | 1.3 | 0.03 | 0.03 | ≥414 | ≥290 | |
| X46 | 0.28 | - | 1.4 | 0.03 | 0.03 | ≥434 | ≥317 | |
| X52 | 0.28 | - | 1.4 | 0.03 | 0.03 | ≥455 | ≥359 | |
| X56 | 0.28 | - | 1.4 | 0.03 | 0.03 | ≥490 | ≥386 | |
| X60 | 0.28 | - | 1.4 | 0.03 | 0.03 | ≥517 | ≥448 | |
| X65 | 0.28 | - | 1.4 | 0.03 | 0.03 | ≥531 | ≥448 | |
| X70 | 0.28 | - | 1.4 | 0.03 | 0.03 | ≥565 | ≥483 | |
| API 5L PSL2 | B | 0.24 | - | 1.2 | 0.025 | 0.015 | ≥414 | ≥241 |
| X42 | 0.24 | - | 1.3 | 0.025 | 0.015 | ≥414 | ≥290 | |
| X46 | 0.24 | - | 1.4 | 0.025 | 0.015 | ≥434 | ≥317 | |
| X52 | 0.24 | - | 1.4 | 0.025 | 0.015 | ≥455 | ≥359 | |
| X56 | 0.24 | - | 1.4 | 0.025 | 0.015 | ≥490 | ≥386 | |
| X60 | 0.24 | - | 1.4 | 0.025 | 0.015 | ≥517 | ≥414 | |
| X65 | 0.24 | - | 1.4 | 0.025 | 0.015 | ≥531 | ≥448 | |
| X70 | 0.24 | - | 1.4 | 0.025 | 0.015 | ≥565 | ≥483 | |
| X80 | 0.24 | - | 1.4 | 0.025 | 0.015 | ≥621 | ≥552 | |
1. Product Name: Seamless line pipe, oil and gas pipe, fluid transport pipe, api 5l seamless pipe, ASTM A106 Seamless line pipe
2. Sizes and Dimensions:
Seamless line pipes are available in a wide range of sizes, typically specified by outer diameter (OD) and wall thickness (WT). Common sizes range from 1/8 inch to 24 inches in diameter, with wall thicknesses varying based on the pressure requirements.
3. Material Grades:
Carbon Steel: Such as API 5L Grade B, X42, X52, X60, X65, X70, etc.
Alloy Steel: Used for enhanced strength and corrosion resistance.
Stainless Steel: For applications requiring high corrosion resistance.
4. Ends: Square Ends/Plain Ends (straight cut, saw cut, torch cut), Beveled/Threaded Ends
1. Oil and Gas Industry
Seamless line pipes are extensively used in the oil and gas industry for their durability and resistance to high pressures and corrosive environments. They are employed in:
Drilling Operations: For casing and tubing in oil wells.
Transmission Pipelines: For transporting crude oil and natural gas over long distances.
Refineries and Processing Plants: For internal piping systems that handle high-pressure fluids.
2. Water and Wastewater Treatment
In water and wastewater treatment plants, seamless line pipes are used for:
Distribution Systems: For transporting potable water.
Wastewater Pipelines: For handling corrosive wastewater.
3. Marine and Offshore
Seamless line pipes are used in marine applications for:
Shipbuilding: For ship hulls, propeller shafts, and other critical components.
Offshore Platforms: For structural components and fluid transportation systems.
Seamless line pipes have no welds, ensuring higher strength and durability, making them ideal for high-pressure applications.
They withstand extreme conditions, making them suitable for oil and gas pipelines in harsh environments.
Made from high-quality steel, they offer excellent resistance to corrosion and abrasion, ensuring long-term performance.
Seamless pipes have a smooth interior, reducing friction and improving fluid flow efficiency.
They are used in various industries, including oil and gas, petrochemical, and water distribution, and are customizable to project needs.
Manufactured to API 5L, ASTM A106, and ISO 3183 standards, ensuring high quality and reliability.
