API 5CT P110 tubing pipe is a high-grade steel pipe used in the oil and gas industry, adhering to the API 5CT standard. It is designed for extreme conditions, offering exceptional tensile and yield strength, making it suitable for deep, high-pressure, and high-temperature wells.
This pipe is designed to provide structural support and transport fluids such as oil and gas from the reservoir to the surface. It is commonly used in high-pressure environments in deep wells.
While it lacks the corrosion resistance of lower grades like L80, its unmatched strength makes it ideal for non-corrosive, high-performance environments. Its durability and reliability ensure long-term well integrity in extreme drilling and production conditions.
| product name | API-5CT tubing Pipe, P110 tubing Pipe, API-5CT tubing, Oil tubing pipe, Oil well tubing, tubing pipe oil and gas, Oil field tubing Pipe |
| Outer Diamater | 48.26mm-114.3mm |
| Wall Thickness | 3.18mm-16mm |
| Thread Type | NUE, EUE, STC, LTC, BTC, XC, HYDRILL CS |
| Standards | API 5CT PSL1/PSL2 |
| Steel Grade | H40 J55 K55 N80 N80Q L80 P110 T95 Q125 |
| Surface Treatment | Hot Rolled |
| Special Pipe | API Pipe, Thick Wall Pipe, Other |
| Application | Fluid Pipe, Boiler Pipe, Drill Pipe, Hydraulic Pipe, OIL PIPE, Gas Pipe, Chemical Fertilizer Pipe |
| Certificate | API, ISO9001 |
| Length | R1, R2, R3 |
| MOQ | 1 ton |
| Packing | Standard Seaworthy Packing |
| Supply Ability | 3000Tons per Month |
| API 5CT P110 Chemical Composition | ||||||||||
| Grade | Carbon (C) | Manganese (Mn) | Phosphorus (P) | Sulfur (S) | Silicon (Si) | Chromium (Cr) | Molybdenum (Mo) | Nickel (Ni) | Copper (Cu) | Vanadium (V) |
| API 5CT P110 | 0.26–0.35 | 1.40 max | 0.030 max | 0.030 max | 0.20–0.45 | 0.15–0.35 | 0.15–0.35 | 0.20 max | 0.20 max | 0.02–0.08 |
| API 5CT N80 Mechanical Property | ||||||
| Grade | Total elongation under load (%) | Yield strength (min) | Yield strength (max) | Tensile strength min Mpa | Hardness Max (HRC) | Hardness Max (HBW) |
| P110 | 0.6 | 758 | 965 | 862 | - | - |
| Label | OD (mm) | WT (mm) | Type of End-finish | |||||||||
| Inch | NU T&C | EU T&C | IJ | H40 | J55 | L80 | N80 | C90 | T95 | P110 | ||
| 1.9 | 2.75 | 2.9 | 2.76 | 48.26 | 3.68 | PNUI | PNUI | PNUI | PNUI | PNUI | PNUI | - |
| 1.9 | 3.65 | 3.73 | - | 48.26 | 5.08 | PU | PU | PU | PU | PU | PU | PU |
| 1.9 | 4.42 | - | - | 48.26 | 6.35 | - | - | P | - | P | P | - |
| 2 3/8 | 4 | - | - | 60.32 | 4.24 | PU | PN | PN | PN | PN | PN | - |
| 2 3/8 | 4.6 | 4.7 | - | 60.32 | 4.83 | PNU | PNU | PNU | PNU | PNU | PNU | PNU |
| 2 3/8 | 5.8 | 5.95 | - | 60.32 | 6.45 | - | - | PNU | PNU | PNU | PNU | PNU |
| 2 3/8 | 6.6 | - | - | 60.32 | 7.49 | - | - | P | - | P | P | - |
| 2 3/8 | 7.35 | 7.45 | - | 60.32 | 8.53 | - | - | PU | - | PU | PU | - |
| 2 7/8 | 6.4 | 6.5 | - | 73.02 | 5.51 | PNU | PNU | PNU | PNU | PNU | PNU | PNU |
| 2 7/8 | 7.8 | 7.9 | - | 73.02 | 7.01 | - | - | PNU | PNU | PNU | PNU | PNU |
| 2 7/8 | 8.6 | 8.7 | - | 73.02 | 7.82 | - | - | PNU | PNU | PNU | PNU | PNU |
| 2 7/8 | 9.35 | 9.45 | - | 73.02 | 8.64 | - | - | PU | - | PU | PU | - |
| 2 7/8 | 10.5 | - | - | 73.02 | 9.96 | - | - | P | - | P | P | - |
| 3 1/2 | 7.7 | - | - | 88.9 | 5.49 | PN | PN | PN | PN | PN | PN | - |
| 3 1/2 | 9.2 | 9.3 | - | 88.9 | 6.45 | PNU | PNU | PNU | PNU | PNU | PNU | PNU |
| 3 1/2 | 10.2 | - | - | 88.9 | 7.34 | PN | PN | PN | PN | PN | PN | - |
| 3 1/2 | 12.7 | 12.95 | - | 88.9 | 9.52 | - | - | PNU | PNU | PNU | PNU | PNU |
| 3 1/2 | 14.3 | - | - | 88.9 | 10.92 | - | - | P | - | P | P | - |
| 3 1/2 | 15.5 | - | - | 88.9 | 12.09 | - | - | P | - | P | P | - |
| 4 | 9.5 | - | - | 101.6 | 5.74 | PN | PN | PN | PN | PN | PN | - |
| 4 | 10.7 | 11 | - | 101.6 | 6.65 | PU | PU | PU | PU | PU | PU | - |
| 4 | 13.2 | - | - | 101.6 | 8.38 | - | - | P | - | P | P | - |
| 4 | 16.1 | - | - | 101.6 | 10.54 | - | - | P | - | P | P | - |
| 4 1/2 | 12.6 | 12.75 | - | 114.3 | 6.88 | PNU | PNU | PNU | PNU | PNU | PNU | - |
| 4 1/2 | 15.2 | - | - | 114.3 | 8.56 | - | - | P | - | P | P | - |
API 5CT P110 tubing pipe is a high-performance steel tube designed for extreme oil and gas well conditions. Its primary advantage lies in its exceptional tensile and yield strength, making it ideal for deep, high-pressure, and high-temperature wells. P110 tubing can withstand significant internal and external pressures, ensuring wellbore stability and safe production operations in challenging environments.
Another key advantage is its durability and reliability in demanding applications, such as hydraulic fracturing, deepwater drilling, and high-stress reservoirs. The heat-treated construction of P110 tubing enhances its mechanical properties, providing long-term performance in extreme conditions. While it lacks the corrosion resistance of lower grades like L80, its unmatched strength makes it suitable for non-corrosive, high-performance environments.
P110 tubing also complies with API 5CT standards, ensuring consistent quality, reliability, and compatibility with other well components. Its robust design and superior strength make it a preferred choice for operators seeking high-performance tubing for deep and high-pressure wells. Despite its higher cost compared to lower grades, P110 tubing offers excellent value for extreme drilling and production applications, ensuring well integrity and operational efficiency.
