API 5CT L80 tubing pipe is a medium-grade steel pipe used in the oil and gas industry, adhering to the API 5CT standard. It has a minimum yield strength of 552 MPa and a minimum tensile strength of 655 MPa.
This pipe is designed to provide structural support and transport fluids such as oil and gas from the reservoir to the surface. It is particularly suitable for wells with corrosive fluids, especially those containing hydrogen sulfide (H2S), due to its enhanced corrosion resistance.
The L80 grade is available in different types, such as Type 1, 3Cr, 9Cr, and 13Cr, with varying chromium content to meet specific corrosion resistance needs.
| product name | API-5CT tubing Pipe, L80 tubing Pipe, API-5CT tubing, Oil tubing pipe, Oil well tubing, tubing pipe oil and gas, Oil field tubing Pipe |
| Outer Diamater | 48.26mm-114.3mm |
| Wall Thickness | 3.18mm-16mm |
| Thread Type | NUE, EUE, STC, LTC, BTC, XC, HYDRILL CS |
| Standards | API 5CT PSL1/PSL2 |
| Steel Grade | H40 J55 K55 N80 N80Q L80 P110 T95 Q125 |
| Surface Treatment | Hot Rolled |
| Special Pipe | API Pipe, Thick Wall Pipe, Other |
| Application | Fluid Pipe, Boiler Pipe, Drill Pipe, Hydraulic Pipe, OIL PIPE, Gas Pipe, Chemical Fertilizer Pipe |
| Certificate | API, ISO9001 |
| Length | R1, R2, R3 |
| MOQ | 1 ton |
| Packing | Standard Seaworthy Packing |
| Supply Ability | 3000Tons per Month |
| API 5CT L80 Chemical Composition | ||||||||||
| Grade | Carbon (C) | Manganese (Mn) | Phosphorus (P) | Sulfur (S) | Silicon (Si) | Chromium (Cr) | Molybdenum (Mo) | Nickel (Ni) | Copper (Cu) | Vanadium (V) |
| API 5CT L80 | 0.43 max | 1.90 max | 0.030 max | 0.030 max | 0.45 max | 0.15–0.35 | 0.15–0.35 | 0.25 max | 0.35 max | 0.02–0.08 |
| API 5CT L80 Mechanical Property | |||||||
| Grade | Type | Total elongation under load (%) | Yield strength (min) | Yield strength (max) | Tensile strength min Mpa | Hardness Max (HRC) | Hardness Max (HBW) |
| L80 | 1 | 0.5 | 552 | 655 | 655 | 23 | 241 |
| L80 | 9Cr | 0.5 | 552 | 655 | 655 | 23 | 241 |
| L80 | 13Cr | 0.5 | 552 | 655 | 655 | 23 | 241 |
| Label | OD (mm) | WT (mm) | Type of End-finish | |||||||||
| Inch | NU T&C | EU T&C | IJ | H40 | J55 | L80 | N80 | C90 | T95 | P110 | ||
| 1.9 | 2.75 | 2.9 | 2.76 | 48.26 | 3.68 | PNUI | PNUI | PNUI | PNUI | PNUI | PNUI | - |
| 1.9 | 3.65 | 3.73 | - | 48.26 | 5.08 | PU | PU | PU | PU | PU | PU | PU |
| 1.9 | 4.42 | - | - | 48.26 | 6.35 | - | - | P | - | P | P | - |
| 2 3/8 | 4 | - | - | 60.32 | 4.24 | PU | PN | PN | PN | PN | PN | - |
| 2 3/8 | 4.6 | 4.7 | - | 60.32 | 4.83 | PNU | PNU | PNU | PNU | PNU | PNU | PNU |
| 2 3/8 | 5.8 | 5.95 | - | 60.32 | 6.45 | - | - | PNU | PNU | PNU | PNU | PNU |
| 2 3/8 | 6.6 | - | - | 60.32 | 7.49 | - | - | P | - | P | P | - |
| 2 3/8 | 7.35 | 7.45 | - | 60.32 | 8.53 | - | - | PU | - | PU | PU | - |
| 2 7/8 | 6.4 | 6.5 | - | 73.02 | 5.51 | PNU | PNU | PNU | PNU | PNU | PNU | PNU |
| 2 7/8 | 7.8 | 7.9 | - | 73.02 | 7.01 | - | - | PNU | PNU | PNU | PNU | PNU |
| 2 7/8 | 8.6 | 8.7 | - | 73.02 | 7.82 | - | - | PNU | PNU | PNU | PNU | PNU |
| 2 7/8 | 9.35 | 9.45 | - | 73.02 | 8.64 | - | - | PU | - | PU | PU | - |
| 2 7/8 | 10.5 | - | - | 73.02 | 9.96 | - | - | P | - | P | P | - |
| 3 1/2 | 7.7 | - | - | 88.9 | 5.49 | PN | PN | PN | PN | PN | PN | - |
| 3 1/2 | 9.2 | 9.3 | - | 88.9 | 6.45 | PNU | PNU | PNU | PNU | PNU | PNU | PNU |
| 3 1/2 | 10.2 | - | - | 88.9 | 7.34 | PN | PN | PN | PN | PN | PN | - |
| 3 1/2 | 12.7 | 12.95 | - | 88.9 | 9.52 | - | - | PNU | PNU | PNU | PNU | PNU |
| 3 1/2 | 14.3 | - | - | 88.9 | 10.92 | - | - | P | - | P | P | - |
| 3 1/2 | 15.5 | - | - | 88.9 | 12.09 | - | - | P | - | P | P | - |
| 4 | 9.5 | - | - | 101.6 | 5.74 | PN | PN | PN | PN | PN | PN | - |
| 4 | 10.7 | 11 | - | 101.6 | 6.65 | PU | PU | PU | PU | PU | PU | - |
| 4 | 13.2 | - | - | 101.6 | 8.38 | - | - | P | - | P | P | - |
| 4 | 16.1 | - | - | 101.6 | 10.54 | - | - | P | - | P | P | - |
| 4 1/2 | 12.6 | 12.75 | - | 114.3 | 6.88 | PNU | PNU | PNU | PNU | PNU | PNU | - |
| 4 1/2 | 15.2 | - | - | 114.3 | 8.56 | - | - | P | - | P | P | - |
API 5CT L80 tubing pipe offers high strength with a minimum yield strength of 552 MPa and a minimum tensile strength of 655 MPa. This makes it suitable for medium to deep wells with higher pressure conditions. Its durability ensures long-term reliability and reduces the risk of failure.
L80 tubing pipe is available in various types, including Type 1, 3Cr, 9Cr, and 13Cr, with different chromium content levels. These options provide enhanced corrosion resistance, making the pipe suitable for wells with corrosive fluids, such as those containing hydrogen sulfide (H2S) or other corrosive substances.
The versatility of API 5CT L80 tubing pipe makes it suitable for a wide range of applications, including onshore and offshore drilling operations. It can be used in various well depths and geological conditions, providing a reliable solution for different drilling needs.
Despite its high strength and corrosion resistance, L80 tubing pipe is often more cost-effective than higher-grade materials. This makes it an economical choice for applications where high strength and corrosion resistance are required but extreme conditions are not present.
